          Ice Water Thermal Shock splash water Test Chamber


           This test simulates a thermal shock induced by ice water and applies to products in the splash areas of the vehicle. The purpose of this test is to simulate ice water splashing over a hot system/component. This happens when driving on wet roads during the winter. Failure modes are mechanical cracking of materials or seal failures caused by different temperature expansion coefficients. An additional failure mode not addressed in 5.3.2.1 is a loss of tightness and the intrusion of water into the system/component.










          Description



          Product Description：
          ISO 16750 Ice Water Thermal Shock splash water Test Chamber
          Type：BND-BSFJ-1000L

          Test Purpose:
          This test simulates a thermal shock induced by ice water and applies to
products in the splash areas of the vehicle. The purpose of this test is to
simulate ice water splashing over a hot system/component. This happens when
driving on wet roads during the winter. Failure modes are mechanical cracking of
materials or seal failures caused by different temperature expansion
coefficients. An additional failure mode not addressed in 5.3.2.1 is a loss of
tightness and the intrusion of water into the system/component.

          Test standards:
          ISO 16750-4: 2006/GB/T 28046.4-2011

          Structural parameters
          External dimensions
          About 1500*deep 1900*high 2250 mm
          Inner box size
          About 1000*Inlet depth 1000*height 1000 mm
          Number of spray holes
          1 sewing spray torion;
          Spraying position
          On the right side of the inner box
          Spirit and sample distance
          325 ± 25mm (manual adjustment)
          Function parameters
          High temperature room temperature range
          RT+10℃～150℃
          Heating rate
          RT+10℃～150℃≤45min
          Water temperature control range
          （0～+4）℃
          Cooling rate
          25℃～2℃≤60min
          Water spray
          （3～4）L/3S
          Test liquid values
          Remove water or+3%Arizona fine dust
          Spray time per cycle (30 minutes)
          3s, interval time: interval time: 29m57s (touch screen setting)
          Number of cycles
          100 times (touch screen setting)
          Electrical parameter
          Device power supply
          380V/50Hz, three -phase and five -line system
          equipment power
          12.0KW
          Safety protection function
          Leakage protection, water deficiency protection, short circuit protection, phase sequence protection, heat overload protection
          ICE-WATER-SPLASH-TESTER (1).jpg
